Revolver 030 3500kv

The Holmes Revolver 030

• 3500kv
• 2-3s lipo
• 10mm (030 and 050) and 9mm mounting pattern
• 1.5mm shaft with 11 tooth Mod.3 brass pinion
• 12 pole 9 slot
• 11mm OD x 9mm L stator
• 14 grams
• 16 x 19mm
• Holmes magnetics and housing
• Standard Micro 3 pin plug

The Holmes Revolver 030 is a tiny outrunner with universal 030, 050, and 9mm bolt pattern for mini and micro rig use. The shape of the motor fits in stock SCX30 chassis, plus most aftermarket transmissions and motor plates. Tuned magnetics give excellent torque and power in an extremely small size, this thing is a little beast! You will need a brushless ESC to power the motor, it is not compatible with stock brushed ESCs. 2200kv version is perfect for general crawling and trail use.  3500kv for when you want to get a little wild!

Double check that the motor does not rub anything after installation, this will damage the motor and your rig.

1 year warranty.  Does not cover overheating, water damage, or improper installation damages.
